Features:​

• Real-time monitoring (Speed/Torque/Cadence/System temperature)​
• Real-time self Diagnosis and Abnormal Warning​
• Trip History and Diagnosis Records​
• Bike Setting and Control (brightness/auto sleep/ password/Assist level performance tuning)​
• Riding logs upload to Cloud Server​
• Remote Firmware Update (OTA)​
• Trouble shooting

Specifications:​

• Rated voltage: 250 ACV​
• Rated current: 2A (signal) & 20A (power)​
• Temperature: -40 ~ 105 ℃​
• Conductor resistance ≦ 2 Ohm​
• Cable insulation resistance ≧ 20 Ohm​
• IP rating: IP67​

Display:​

• 1.77”, 128 x 160mm TFT LCD​
• 250Kbps CAN bus communication​
• 2.4GHz Bluetooth low energy version 5.0​
• 32-Bit Arm® Cortex®- M0 + MCU​
• IP rating: IP67​

​

Control Unit:​

• 3 buttons​
• Button function: Up, down and mode​
• IP rating: IP67​

Specifications:​

• Frame battery 20Ah, 960Wh
• Rear hub motor 48V, 750W, MAX 80Nm
• Motor controller 750W
• Display 1.77” LCD
• Control unit 3 buttons
• Torque sensor
• Y slipper cable for motor controller to HMI



Features:​

• Real-time monitoring (Speed/Torque/Cadence/System temperature)​
• Real-time self Diagnosis and Abnormal Warning​
• Trip History and Diagnosis Records​
• Bike Setting and Control (brightness/auto sleep/ password/Assist level performance tuning)​
• Riding logs upload to Cloud Server​
• Remote Firmware Update (OTA)​
• Trouble shooting

Specifications:​

• Rated voltage: 250 ACV​
• Rated current: 2A (signal) & 20A (power)​
• Temperature: -40 ~ 105 ℃​
• Conductor resistance ≦ 2 Ohm​
• Cable insulation resistance ≧ 20 Ohm​
• IP rating: IP67​

Display:​

• 1.77”, 128 x 160mm TFT LCD​
• 250Kbps CAN bus communication​
• 2.4GHz Bluetooth low energy version 5.0​
• 32-Bit Arm® Cortex®- M0 + MCU​
• IP rating: IP67​

​

Control Unit:​

• 3 buttons​
• Button function: Up, down and mode​
• IP rating: IP67​
