Wheel Size : 700*45C Cyclo Cross Bike
Steerer Diameter : Ø 28.6mm*1"1/8 or 1"1/2
Blade Diameter : Ø 31.8mm, Taper
Material : 3Al 2.5V Seamless DB Titanium Tubes
Offset : 45 mm
Internal Cable Routing
Dropout: x-15 Flat Mount One-Piece Design

• 700*32C Road Bike Frame
• 3Al 2.5V Titanium Butted Heat Treatment Tubes :
T/T OD40*1.2/0.7/0.9 Taper To 31.8mm T41
D/T OD47*1.2/0.7/0.9mm D41
S/T OD40*1.45/0.7/1.0mm Taper To 31.8mm
S/S OD16*0.9mm Taper To 12.7mm S01
C/S OD22.2*0.9mm C36
• Head Tube OD55/ID52
• BB Shell T47
• UDH Dropout With Flat Mount B09BT2261A
• Internal Cable Routing
• Custom Sizing

Diameter : 28.6mm
Material : 6Al 4V Titanium
Bar Bore : 31.8mm
Angle : ± 0° / ± 6°
Extension : 80/90/100/110/120 mm
Compatible Headset : ORA / TOKEN / FSA / Chris King

Wheel Size : 700*45C Cyclo Cross Bike
Steerer Diameter : Ø 28.6mm*1"1/8 or 1"1/2
Blade Diameter : Ø 31.8mm, Taper
Material : 3Al 2.5V Seamless DB Titanium Tubes
Offset : 45 mm
Internal Cable Routing
Dropout: x-15 Flat Mount One-Piece Design

• 700*32C Road Bike Frame
• 3Al 2.5V Titanium Butted Heat Treatment Tubes :
T/T OD40*1.2/0.7/0.9 Taper To 31.8mm T41
D/T OD47*1.2/0.7/0.9mm D41
S/T OD40*1.45/0.7/1.0mm Taper To 31.8mm
S/S OD16*0.9mm Taper To 12.7mm S01
C/S OD22.2*0.9mm C36
• Head Tube OD55/ID52
• BB Shell T47
• UDH Dropout With Flat Mount B09BT2261A
• Internal Cable Routing
• Custom Sizing
